UNV Videowall Model MW-A46-B3

Model	MW‑A46‑B3‑E
Panel
Panel Size	46″
Resolution	1920 × 1080
Bezel Width	B2B: 1.7 mm (Panel to Panel , Without Bezel), 0.9 mm (T/L), 0.8 mm (B/R) A2A: 2.45 mm (Active area to Active area), 1.5 mm (T/L), 0.95 mm (B/R)
Color Support	16.7 M
Brightness (cd/m²)	500
Contrast Ratio	4000:1
Response Time (ms)	8
Viewing Angle (H/V)	178°/178°
Refresh Rate	60 Hz
LCD Technology/Panel Type	ADS
Operation Hour	24/7
Pixel Pitch (H × V) (mm)	0.53 × 0.53
Interface
Video Input	1 × HDMI, 1 × DVI, 1 × VGA, 1 × CVBS, 1 × DP
Video Output	1 × HDMI
Other Interfaces	1 × USB 2.0, 2 × RS232, 1 × IR Interface
OSD
Multi‑Language	English, Simplified Chinese
General
Input Voltage	AC 100 ~ 240 V, 50/60 Hz
Typical Power Consumption (W)	175
Product Dimensions (W × H × D) (mm)	1021.2 × 575.8 × 125.5
Package Dimensions (W × H × D) (mm)	1135 × 705 × 205
Weight (kg)	Net Weight: 20 Gross Weight: 24
Operating Temperature	0℃ ~ 40℃
Operating Humidity	20% ~ 90% (No Condensation)
Storage Temperature	‑20℃ ~ 60℃
Storage Humidity	10% ~ 90% (No Condensation)
Standard	1 × Remote Control, 1 × Power Cable, 1 × Ground Wire, 1 × Infrared E×tension Cable, 1 × Network Cable, 1 × Quick Guide
Lifetime (h)	50000
MTBF	50000h
Color Temperature	10000K
Material	SECC
