| Model | HB-7199-CA-A |
| Image sensor | High quality CMOS sensor |
| Effective pixels | 2 megapixel |
| Video format | 1920×1080/ 1600×896/ 1280×720/ 1024×576/ 960×720/ 960×540/ 912×512 / 864×480/ 800×600/ 800×448/ 640×480/ 640×360/ 624×352/ 480×272 / 432×240/ 424×240/ 384×216/ 368×208/ 320×240/ 320×180/ 272×144 / 160×120/ P30 |
| Camera angle | 88°(D)/80°(H)/ 50°(V) |
| Focal length | 3.24mm |
| Minimum illumination | 0.5Lux(F1.8, AGC ON) |
| Focus mode | Manual |
| Aperture | Fixed |
| Inverse light contrast | Open/close |
| Exposure | Exposure parameters adjustable, support for automatic exposure |
| Video regulation | Luminance, clarity, saturation, contrast ratio, white balance, transmission gain, Anti-flicker, low brightness compensation and other parameters can be adjusted |
| Siginal noise ratio | ＞50dB |
| Video interface | USB 2.0 |
| Video compression format | MJPEG、YUV2、H.264、H.265 |
| Audio input | Built-in high sensitive pickup |
| Working voltage | 5V |
| Working current | 500mA |
| Power | 2.5W |
| Dimension | 102mm(L)×46mm(W)×30mm(H) |
| Weight | 0.15 kg |
| Storage temperature | -10℃～+60℃ |
| Storage humidity | 20℃～95℃ |
| Working temperature | -10℃～+50℃ |
| Working humidity | 20℃～80℃ |
| Operating environment | Indoor |
